Angle Brackets
Angle Brackets provide sturdy support for equipment while using 0U of rack space, allowing customers to maximize every inch of their enclosure. Designed for strength and efficiency, these brackets offer a robust 200 LB weight load capacity, making them an ideal solution for space-conscious, heavy-duty equipment mounting.
Features
- Made of 12GA Steel
- Mounts to Vertical Rack Rails
- Front to Rear Mounting is Adjustable by 6″ to Allow Vertical Rails to be Placed in Various Positions
- 0U
- 200 LB Weight Capacity
- Mounting Hardware Included
- Color: Black
- Powder Coat Finish Available in a Variety of Standard and Custom Colors
- Designed and Manufactured in the USA
- Custom Sizes and Configurations Available Upon Request
Angle Brackets
| PART NUMBER | RACK MOUNT SPACING | HEIGHT | VERTICAL RAIL SPACING | WEIGHT CAPACITY | DRAWING | CAD MODEL |
|---|---|---|---|---|---|---|
| AB1824 | 19″ | 0U | 18-24″ | 200 LBS | Download | Download |
| AB2430 | 19″ | 0U | 24-30″ | 200 LBS | Download | Download |
| AB3036 | 19″ | 0U | 30-36″ | 200 LBS | Download | Download |
| AB3642 | 19″ | 0U | 36-42″ | 200 LBS | Download | Download |
| AB1824-RR1924 | 24″ | 0U | 18-24″ | 200 LBS | Download | Download |
| AB2430-RR1924 | 24″ | 0U | 24-30″ | 200 LBS | Download | Download |
| AB3036-RR1924 | 24″ | 0U | 30-36″ | 200 LBS | Download | Download |
| AB3642-RR1924 | 24″ | 0U | 36-42″ | 200 LBS | Download | Download |
| AB1824-RR1928 | 28″ | 0U | 18-24″ | 200 LBS | Download | Download |
| AB2430-RR1928 | 28″ | 0U | 24-30″ | 200 LBS | Download | Download |
| AB3036-RR1928 | 28″ | 0U | 30-36″ | 200 LBS | Download | Download |
| AB3642-RR1928 | 28″ | 0U | 36-42″ | 200 LBS | Download | Download |
